This is an upgrade high flow turbocharger replacement to replace factory GT3576R / GT3582R turbos, it suits Ford Falcon XR6 BA/BF/FG.
Compressor Specifications
Inducer: 67mm
Exducer: 84mm
A/R: 0.72
Compressor Inlet: 4" Slip fit
Compressor Outlet: 2.5" Slip fit
Turbine Specifications
Inducer: 74mm
Exducer: 66mm
A/R: 1.06 / 1.15
Turbine Inlet Flange: T3
Turbine Outlet Flange: Ford XR6 5-Bolt
- Dual Ceramic Ball Bearing System
- 10 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
- Inconel 713c 10 Blade Turbine Wheel with High Horsepower
- Cover Integrated with the Speed Sensor Port
- Max Air Flow rate: ~90 lb/min, rated @ 1000 FWHP
- Stronger Turbine Wheel for High flow
- Oil Feed: -4 AN connect to the Oil Restrictor
- Water In/Outlet: M14*1.5
- We highly recommended running water cooling for better durability
- Billet actuator with black anodized coating
- 3 Layer Stainless Steel 5 Bolt Gasket
Based off our popular GTX3584RS series turbo, This is very similar but with the larger 66mm rear wheel it has been proven to make up to 70rwkw more than the Gen 2 versions
PSR3584 GEN3 TURBO comes with stronger turbine wheel for high flow.
