Horsepower: 700 - 1050
Displacement: 2.0L - 5.5L
Compressor Specifications
Inducer: 68mm
Exducer: 84mm
Compressor Inlet: 4" Slip fit
Turbine Specifications
Inducer: 68mm
Exducer: 62mm
A/R: 0.83 / 1.01 (optional)
Turbine Inlet: T3 / T4 / V-Band (optional)
Turbine Outlet: 3″ V-Band
Cooling Specifications
Water Ports: 2-M14 X 1.5
Oil Inlet: 7/16-24 UNF with a -4AN Restrictor pre-installed
Oil Outlet: Std T3 Oil Drain Flange
- Dual ceramic ball bearing system provides optimal turbo response and
better durability by reducing the shaft-motion - 9 Blade G-Aero billet compressor wheel with extended tapered tip technology
- 9 Blade G-Aero Inconel 713c turbine wheel
- Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
